Deskripsi
APPLICATIONS
- Water circulation for domestic use.
- Home lawn and garden sprinkler systems.
- Washing and transfer.
- Applications where keeping the pump primed is problema.
SPECIFICATIONS
- Delivery: up to 45 l/min (2,7 m3/h).
- Head: up to 49,3 m.
- Maximum operating pressure: 8 bar.
- Continuous duty.
- Temperature of pumped liquid: -10°C to +40°C.
- Max ambient temperature: 40°C.
- Enclosed motor with external ventilation and aluminium alloy finned casing.
- Versions:
Single-phase 220-240 V 50 Hz, permanently connected capacitor and built-in automatic reset overload protection.
Three-phase 220-240/380-415 V 50 Hz, thermal overload protection to be provided by user. - Power up to 0.75 kW.
- Class F Insulation.
- IP 55 protection.
